Dispensing Equipment
Dymax manual and automated fluid dispense systems and spray valves are easily integrated into existing manufacturing processes for easy application of coatings, lubricants, or masking resins.
Peelable Maskants
Light-Curable Peelable Maskants for Electronic Applications
Protect components during conformal coating, soldering, and reflow with Dymax SpeedMask® peelable maskants. The masking materials cure in seconds “on-demand” when exposed to UV/Visible light. Just one layer of masking material provides excellent protection of printed circuit and wiring boards during processing. Bondable substrates include lead frame, ceramic, PCB, flex, as well as silicon. They are also compatible with gold and copper connector pins and wires.
After full cure, the masks peel off cleanly, eliminating the concern of ionic contamination or silicone left behind other masking methods. Fluorescing grades are available for post-cure quality inspection.
Dymax formulations are highly thixotropic and/or non-slumping for manual or automated dispensing onto difficult components.
Features
- Cure with LED or UV/Visible light
- Complete cure in seconds
- Residue free upon removal
- One part formulation - no mixing
- No solvents added
- Silicone free
- Replace tape, wax and lacquer waxing methods
Light-Curable Peelable Maskants for Electronic Applications
Light-Curable Peelable Maskants for Electronic Applications
Dymax peelable maskants for electronics cure in seconds when exposed to UV/Visible light. The products are all one part, solvent free, and silicone free. The formulations are highly thixotropic for manual or automated dispensing onto difficult components prior to conformal coating applications, wave soldering, or reflow operations. After full cure, the masks peel off cleanly.
Product Number
Product Description
Regional Availability
9-7001
PCB protective maskant with color change upon cure provides one-layer protection with a rack free cure up to 0.5 in [12.7 mm]. This maskant is compatible with gold and copper connector pins and resists solvent-based conformal coatings and primers. For enhanced visibility, this product dispenses pink, transitions to clear upon cure, and features a blue fluorescing tracer.
726-SC
UV-curable maskant with color change from blue to pink upon cure. This resin is resistant to plating, anodizing, air plasma spray, grit blasting, and shot peening. This product remains flexible at higher temperatures and can be removed by peeling after exposure to heat.
9-20479-B-REV-A
Blue PCB protective maskant. This UV-curable maskant is compatible with gold and copper connector pins. The product is easily removable, eliminating the concern of ionic contamination or silicone left behind by other methods.
Product Number
Product Description
Regional Availability
9-318-F
Fluorescing and peelable maskant designed for rapid masking of electronic components and assemblies to protect from reflow or wave soldering operations. This product is highly thixotropic for easy dispensing on boards or components that may be difficult to mask with other methods.
Need help, use the product finder
Use our formulated product finder to help you find the right material. Interested in learning more or have questions? Contact Us, we want to hear from you.
